DDC articulated trolley

For travel on tight curved track

DDC articulated monorail hoist for travel on curved track

R/EUDDC (standard-headroom) and R/EKDDC (low-headroom) monorail travelling hoists with articulated trolleys are ideally suited for travel on curved tracks made of I-beam girders. DDC units are the solution for normal or low-headroom applications for a minimum curve radius of 800 mm. Their lateral guide rollers provide for quiet travel characteristics that are kind to the track.

Adapted to meet your needs

Demag geared motors can be installed as an option, making the trolley suitable for electric travel with even more convenient control via a radio or pendant controller. The installation of an angular gearbox also allows the unit to travel through narrow openings.

Product information

The benefits at a glance

DDC articulated trolley

Suitable for travel on curved tracks with I-beam girders for curve radii of at least 800 mm
Lateral guide rollers for quiet operation and gentle on the runway
Travel motor can be optionally mounted on angular gearbox for travel through narrow openings
Available as standard or low-headroom variants

Customer benefits at a glance

Safety

Low-voltage control pendant thanks to 24 V contactor control system
Safety-related functions satisfy at least Performance Level c and Category 2 to EN ISO 13849-1

Minimum load sway

Smooth cross-travel starting and braking motions for low-sway load handling
Speeds and acceleration/braking rates can be modified by means of the control pendant, if required

Long service life

Generously specified gearbox. 2m+ (1,900 hours) for main load capacities and up to 4m (6,300 hours) for demanding applications
All sub-assemblies of the chain hoist are rated for a long service life, even under the most demanding conditions

Temperature range

Reliable operation from -20 °C to +45 °C without any reduction in the duty factor
Operation also possible up to 60 °C and more

Ergonomics

Length of control cable or position of control pendant can be adjusted without the need for any wiring
Length of control cable that is not needed can be stored under the service cover

High-performance motor

Hoist motor has large safety reserves to provide for reliable operation for many years
Can be used for switching cycles way beyond usual market levels

Pro-Hub function

Up to 90% higher rated lifting speed in reduced load range

Easy to service

Gearbox & slipping clutch maintenance-free for up to 10 years
Brake maintenance-free for up to 10 years (up to 5 years for DC 10–25)
Simple and rapid maintenance and repair of individual components thanks to the modular chain hoist design – cuts any downtime to a minimum

Variable speeds

Valuable and sensitive parts can be moved and positioned more smoothly and reliably
Variable button characteristic like a car accelerator pedal

Status display

Display for elapsed operating time counter and operating statuses
Always up-to-date for service purposes

Slipping clutch monitoring

Harmful continuous slipping eliminated thanks to speed monitoring
Reliable protection against extreme overload
Load securely held in any operating situation and cannot drop while hoist is at standstill, since brake is arranged in front of the slipping clutch in load-bearing arrangement
